Description
Category: professional.
The trainer is designed for training the muscles of the lower leg (calf muscle).
Exercise:
1. Standing toe raises.
Description:
– The supporting structure is made of 60×60 mm profile, wall thickness 2 mm.
– The structure has radial bends, which significantly increases its strength.
– The frame is painted by powder coating method.
– The weight block is used as a weighting device, consisting of steel plates covered with PVC, which makes the work on the trainer silent.
– The weight block is driven by a 20 mm wide, 2.6 mm thick polyamide belt with a tensile strength of 390 N/mm2 and a maximum load of 1500 kg.
– The force is transmitted by means of only 2 roller blocks, which simplifies the construction and increases the reliability of the mechanism.
– The load is adjusted by adjusting the adjusting pin (lock) fixed on the elastic cord.
– The flute and guides are plated with a complex galvanic coating of nickel and chrome.
– Load block protection is made of impact-resistant polystyrene.
– Ball bearings installed on all rotational units ensure reliable and comfortable use of the trainer.
– Cushion-supports and footrest are made of five-layer plywood 18 mm thick and polyurethane foam.
– The height of the starting position is adjustable according to the athlete’s height and has 8 fixed positions with a step of 30 mm.
– For convenient use of the trainer there are PVC handles.
– To eliminate slipping, the product is equipped with PVC footrests.
